Effects.VolumeAutomationPointSetParameters method

Previous pageReturn to chapter overviewNext page

Remarks



Sets parameters of an existing volume point.



For further details about defining a volume automation procedure refer to the How to define a volume automation procedure section.

For further details about methods related to the use of special effects refer to the EffectsMan class.





Syntax



[Visual Basic]

Public Function VolumeAutomationPointSetParameters (

nIndexVolumePoint as Int32,

fPosition as float,

fVolumeLevel as float,

nCurveType as enumVolumeCurves

) as enumErrorCodes




[C#]

public enumErrorCodes VolumeAutomationPointSetParameters (

Int32 nIndexVolumePoint,

float fPosition,

float fVolumeLevel,

enumVolumeCurves nCurveType

);




[C++]

public: enumErrorCodes VolumeAutomationPointSetParameters (

Int32 nIndexVolumePoint,

float fPosition,

float fVolumeLevel,

enumVolumeCurves nCurveType

);






Parameter

Description





nIndexVolumePoint

Zero-based index of the volume point

fPosition

Position, expressed in the unit set through the Effects.VolumeAutomationSetScales method, where the volume point will be applied

fVolumeLevel

Volume applied starting from the current automation point: the value is expressed in the unit set through the Effects.VolumeAutomationSetScales method.

nCurveType

Type of curve applied to reach the next volume point.

Supported values are the following:

Mnemonic constant

Value

Meaning







VOLUME_CURVE_NONE

0

No curve is applied: volume will be changed immediately and will be kept till next volume point.

VOLUME_CURVE_LINEAR

1

Linear curve

VOLUME_CURVE_EXPONENTIAL

2

Exponential curve

VOLUME_CURVE_COSINE

3

Cosine curve

VOLUME_CURVE_SMOOTH

4

Smooth curve

VOLUME_CURVE_CUSTOM

5

Custom Bézier curve.





Return value



Value

Meaning





Negative value

An error occurred (see the LastError property for further error details)

enumErrorCodes.ERR_NOERROR (0)

The method call was successful.
