How to use enumerated types

Previous pageReturn to chapter overviewNext page

The use of enumerated types improves the readability of your code and, thanks to the features offered by Microsoft's Intellisense, will ease the coding phase.



The following is the full list of enumerated types with their associated properties:



Enumerated type

Corresponding properties or parameters

enumWanErrorCodes

LastError property

enumWaveformTypes

nWaveformType parameter of the BitmapViewSaveToFile and GetMinMaxPeakLevelsForRange methods

enumTrackerCursorModes

nCursorMode parameter of the SetTrackerCursors method

enumAnalyzerResolutions

nResolution field of the WANALYZER_GENERAL_SETTINGS data structure

enumWaveformStereoModes

nStereoVisualizationMode field of the WANALYZER_WAVEFORM_SETTINGS and WSCROLLER_SETTINGS data structures and nWaveformStereoMode parameter of the BitmapViewDrawToHdc method

enumVolumeScales

nAmplitudeScale field of the WANALYZER_RULERS_SETTINGS data structure

enumMouseActions

nAction parameter of the WaveAnalyzerMouseNotification event

enumWaveAnalyzerRectangles

nIdRectangle parameter of the GetRectangle method

enumGraphicFormats

nFormat parameter of the BitmapViewSaveToFile method

enumHorizontalLineHeadlineType

nHeadlineType parameter of the GraphicItemHorizontalLineAdd and GraphicItemHorizontalLineParamsSet methods

enumHorizontalLineChannel

nChannel parameter of the GraphicItemHorizontalLineAdd, GraphicItemHorizontalLineParamsSet methods and nChannel field of the WANALYZER_HORIZONTAL_LINE data structure

enumGraphicItemType

nType parameter of the GraphicItemTypeGet, GraphicItemsTypeShow and GraphicItemUniqueIdGet methods

enumGraphicItemMaskValues

nGraphicItemsMask parameter of the GraphicItemsMouseMoveEnable and BitmapViewGraphicItemsMaskSet methods and nGraphicItemsMask field of the WANALYZER_SCROLLBARS_SETTINGS and WSCROLLER_SETTINGS data structures

enumWaveformLineDashStyles

Some field of the WANALYZER_GENERAL_SETTINGS, WANALYZER_VERTICAL_LINE, WANALYZER_HORIZONTAL_LINE and WSCROLLER_SETTINGS data structures

enumLineCaps

Some field of the WANALYZER_GENERAL_SETTINGS, WANALYZER_VERTICAL_LINE, WANALYZER_HORIZONTAL_LINE and WSCROLLER_SETTINGS data structures

enumLineDashCaps

Some field of the WANALYZER_GENERAL_SETTINGS, WANALYZER_VERTICAL_LINE, WANALYZER_HORIZONTAL_LINE and WSCROLLER_SETTINGS data structures

enumBuddyAlignment

nAlignment field of the WANALYZER_BUDDY_PICTURE and WANALYZER_BUDDY_TEXT data structures

enumMouseButtons

nButton parameter of the WaveAnalyzerGraphicItemClick and WaveAnalyzerGraphicItemDblClick events

enumWaveformSelectionMode

nSelectionMode field of the WANALYZER_WAVEFORM_SETTINGS data structure

enumTranspGlassType

nTransparentGlassType field of the WANALYZER_WAVEFORM_SETTINGS and WANALYZER_SCROLLBARS_SETTINGS data structures

enumWaveScrollbarType

nType field of the WANALYZER_SCROLLBARS_SETTINGS data structure

enumScrollbarWaveVisibleRangeType

nVisibleRangeType field of the WANALYZER_SCROLLBARS_SETTINGS data structure

enumWaveScrollerAutoUpdate

nUpdateSpeed field of the WSCROLLER_SETTINGS data structure



The following examples, under different development environments, show how to use enumerated types in your code.



Microsoft Visual Basic.NET

Microsoft Visual C#.NET





Microsoft Visual Basic.NET



After typing the code

If audioWaveformAnalyzerBig.LastError

press the "=" character on your keyboard: IntelliSense automatically displays the enumerated type of the LastError property



Select the enumWanErrorCodes.ERR_WAN_NOERROR value so the complete line of code will be:



If audioWaveformAnalyzerBig.LastError = enumWanErrorCodes.ERR_WAN_NOERROR Then

 ' do something

 ...

Else

 ' do something else

 ...

End If





Microsoft Visual C#.NET



This environment requires a couple of additional lines of code to make use of Intellisense. First, you must add the components namespace to your code so the following line must be inserted at the beginning of the form management file:



using AudioWaveformAnalyzer;



After typing the code...

if (audioWaveformAnalyzerBig.LastError == enumWanErrorCodes

press the "==" sequence of keys followed by a blank character (space) on your keyboard: IntelliSense automatically displays the enumerated type of the LastError property

by pressing the "." (dot) character the IDE will display the list of values accepted by the property:





Select the ERR_WAN_NOERROR value so the complete line of code will be:



if (audioWaveformAnalyzerBig.LastError == enumWanErrorCodes.ERR_WAN_NOERROR)

   // do something

   ....

else

   // do something else

   ....
